DB5053 Anti Vibration Carbide Aluminum End Mills(U-Flute Shape)50°/50.5°/51°-3Flutes
Feature :
◆ With the unique helix design and asymmetry of 50° / 50.5° / 51°, the milling vibration can be greatly reduced to have better tool stability and a smoother surface finish.
◆ Excellent for heavy and high-speed machining to greatly enhance the quality and speed for machining; the best choice for finishing.
◆ Customers individual needs for machining can be met by the special surface treatment and a variety of materials.
A版 / B版
▊DB5053A X 1.5D 單位 : mm (Unit:mm)
| 刀具料號 Model NO. |
刃徑 d Diameter |
刃長 ℓ Flute Length |
頸長 ℓ1 Neck Length |
全長 L Overall Length |
柄徑 D Shank Diameter |
形狀 Figure |
在庫 |
|---|---|---|---|---|---|---|---|
| DB5053AB04A | 4 | 6 | 2.5 | 50 | 4 | Fig.1 | ● |
| DB5053AB04B | ○ | ||||||
| DB5053AC04A | 4 | 6 | 2.5 | 50 | 6 | Fig.2 | ● |
| DB5053AC04B | ○ | ||||||
| DB5053AC06A | 6 | 9 | 3 | 50 | 6 | Fig.1 | ● |
| DB5053AC06B | ○ | ||||||
| DB5053AD08A | 8 | 12 | 4 | 60 | 8 | Fig.1 | ● |
| DB5053AD08B | ○ | ||||||
| DB5053AE10A | 10 | 15 | 4.5 | 60 | 10 | Fig.1 | ● |
| DB5053AE10B | ○ | ||||||
| DB5053AF12A | 12 | 18 | 5 | 60 | 12 | Fig.1 | ● |
| DB5053AF12B | ○ |
刀具料號末碼為A(鋁用) / B(鋼用)版 ○：接單生產品 ●：在庫品 ▲：訂製品
▊DB5053B X 2.5D 單位 : mm (Unit:mm)
| 刀具料號 Model NO. |
刃徑 d Diameter |
刃長 ℓ Flute Length |
頸長 ℓ1 Neck Length |
全長 L Overall Length |
柄徑 D Shank Diameter |
形狀 Figure |
在庫 |
|---|---|---|---|---|---|---|---|
| DB5053BB04A | 4 | 10 | 2.5 | 50 | 4 | Fig.1 | ● |
| DB5053BB04B | ○ | ||||||
| DB5053BC04A | 4 | 10 | 2.5 | 50 | 6 | Fig.2 | ● |
| DB5053BC04B | ○ | ||||||
| DB5053BC06A | 6 | 15 | 3 | 50 | 6 | Fig.1 | ● |
| DB5053BC06B | ○ | ||||||
| DB5053BD08A | 8 | 20 | 4 | 60 | 8 | Fig.1 | ● |
| DB5053BD08B | ○ | ||||||
| DB5053BE10A | 10 | 25 | 4.5 | 75 | 10 | Fig.1 | ● |
| DB5053BE10B | ○ | ||||||
| DB5053BF12A | 12 | 30 | 5 | 75 | 12 | Fig.1 | ● |
| DB5053BF12B | ○ | ||||||
| DB5053BI16A | 16 | 40 | 5 | 100 | 16 | Fig.1 | ● |
| DB5053BI16B | ○ |
刀具料號末碼為A(鋁用) / B(鋼用)版 ○：接單生產品 ●：在庫品 ▲：訂製品
▊DB5053C X 3D 單位 : mm (Unit:mm)
| 刀具料號 Model NO. |
刃徑 d Diameter |
刃長 ℓ Flute Length |
頸長 ℓ1 Neck Length |
全長 L Overall Length |
柄徑 D Shank Diameter |
形狀 Figure |
在庫 |
|---|---|---|---|---|---|---|---|
| DB5053CB04A | 4 | 12 | 2.5 | 50 | 4 | Fig.1 | ● |
| DB5053CB04B | ○ | ||||||
| DB5053CC04A | 4 | 12 | 2.5 | 50 | 6 | Fig.2 | ● |
| DB5053CC04B | ○ | ||||||
| DB5053CC06A | 6 | 18 | 3 | 50 | 6 | Fig.1 | ● |
| DB5053CC06B | ○ | ||||||
| DB5053CD08A | 8 | 24 | 4 | 60 | 8 | Fig.1 | ● |
| DB5053CD08B | ○ | ||||||
| DB5053CE10A | 10 | 30 | 4.5 | 75 | 10 | Fig.1 | ● |
| DB5053CE10B | ○ | ||||||
| DB5053CF12A | 12 | 36 | 5 | 100 | 12 | Fig.1 | ● |
| DB5053CF12B | ○ |
刀具料號末碼為A(鋁用) / B(鋼用)版 ○：接單生產品 ●：在庫品 ▲：訂製品
▊DB5053D X 4D 單位 : mm (Unit:mm)
| 刀具料號 Model NO. |
刃徑 d Diameter |
刃長 ℓ Flute Length |
頸長 ℓ1 Neck Length |
全長 L Overall Length |
柄徑 D Shank Diameter |
形狀 Figure |
在庫 |
|---|---|---|---|---|---|---|---|
| DB5053DB04A1 | 4 | 16 | 2.5 | 60 | 4 | Fig.1 | ● |
| DB5053DB04B1 | ○ | ||||||
| DB5053DC04A1 | 4 | 16 | 2.5 | 60 | 6 | Fig.2 | ● |
| DB5053DC04B1 | ○ | ||||||
| DB5053DC06A | 6 | 24 | 3 | 60 | 6 | Fig.1 | ● |
| DB5053DC06B | ○ | ||||||
| DB5053DD08A | 8 | 32 | 4 | 75 | 8 | Fig.1 | ● |
| DB5053DD08B | ○ | ||||||
| DB5053DE10A | 10 | 40 | 4.5 | 100 | 10 | Fig.1 | ● |
| DB5053DE10B | ○ | ||||||
| DB5053DF12A | 12 | 48 | 5 | 100 | 12 | Fig.1 | ● |
| DB5053DF12B | ○ |
刀具料號末碼為A(鋁用) / B(鋼用)版 ○：接單生產品 ●：在庫品 ▲：訂製品
